Name: Military Night Vision Binocular Reconnaissance Thermal Imager
Brand: OEM, ODM All Available
Price: 1 USD

Place of Origin : China

Brand Name : OEM, ODM All Available

Certification : CE,FC,RoHS

MOQ : 10

Delivery Time : 3~7

Payment Terms : T/T. L/C, Western Union, Money Gram

Supply Ability : 30000PCS/Month

Exit Pupil Diam : 5MM

Sensor : Uncooled LWIR FPA

Range of visual adjustment : -4°～+4°

Working Temperature : -20℃～+50℃

Storage Temperature : -45 ℃~+60℃

Continuous operation time : ≥6h

Starting time : About 10s

Digital interface : USB

Contact Now

High Quality Military Binocular Night Vision Reconnaissance Thermal Imager

Parameter:

Detector and lens
Resolution	640×512
Detector pitch	17μm
NETD	≤45mK@25℃
Spectral Range	8μm～14μm
Frame Frequency	25Hz
Focal Length	46.75 mm
Focus	Manual
Low-level-light(CCD)and lens
Resolution	800×600
Detector pitch	18μm
Frame Frequency	25Hz
Focal Length	49.5 mm
Focus	Manual
Image display
Display	0.39″OLED, 1024×768
Digital zoom	2x
Image adjustment	Auto＆Manual shutter correction;brightness;contrast;polarity;image magnification
Detection and identification range
Detection range	Human 1.7m×0.5m:1550m
Detection range	Vehicle2.3m:2100m
Identification Range	Human 1.7m×0.5m: 500m
Identification Range	Vehicle2.3m:700m
Storage of file
Storage of image	BMP
Storage of video	AVI
Storage card	32G TF
Interface
Video out	Q9
Digital interface	USB
Camera Control	RS232
Tripod mounting	Standard,UNC ¼"-20
Others
Range of visual adjustment	-4°～+4°
Angle shows	Electronic compass
Positioning system	Beidou/GPS
Wireless transmission	WiFi
Laser Designator	Red laser 650 nm
Power supply
Battery	Four 18650 chargeable lithium batteries
Starting up	Long press about 5s
Starting time	About 10s
Continuous operation time	≥6h
Environmental data
Working Temperature	-20℃～+50℃
Storage Temperature	-45 ℃~+60℃
IP Level	IP67
Physical data
Weight	≤1.60kg(including four 18650 lithium batteries )
Size	≤200mm×175mm×94mm

Features:
